Electric Chain Hoist

Product: Chain Hoist

Capacity: 0.25t - 10t

Type: Single Chain and Double Chain

Application: single girder overhead crane, double girder overhead crane, jib crane, gantry crane.

Chat Now

Leave Message

Send Email:info@craneweihua.com

Whatsapp:8613839050298

Overview

Features

Parameter

Application

Overview

Electric Chain Hoist is an efficient and reliable lifting equipment that uses an electric motor to drive the chain to lift and lower. It is suitable for material handling operations in various industrial scenarios. It has a compact structure and is easy to operate. It can be easily integrated into a crane system or used alone to meet the lifting needs of different occasions.

The equipment is equipped with high-strength alloy chains, which are wear-resistant and corrosion-resistant to ensure long-term stable operation. It uses advanced motors and control systems to provide smooth lifting and lowering, and is equipped with safety devices such as overload protection and emergency braking to ensure operational safety. At the same time, the low-noise design and energy-saving motor make it an environmentally friendly and efficient lifting solution.

It is widely used in factory workshops, warehouse logistics, construction sites, equipment maintenance and other scenarios, especially suitable for frequent lifting or space-constrained environments. Whether it is the handling of precision parts on the production line or the installation and maintenance of heavy equipment, Electric Chain Hoist can provide efficient and safe lifting support.

Features

The Electric Chain Hoist combines high efficiency, safety and reliability. It adopts high-strength alloy chain and precision transmission system to ensure smooth and efficient lifting process. It is equipped with safety devices such as overload protection, double brake and limit switch to fully guarantee operation safety. The compact and lightweight design adapts to narrow spaces and supports multiple control modes such as handle, remote control and frequency conversion. It can operate stably in humid, dusty and extreme environments, significantly reducing maintenance costs. It is an ideal lifting solution for improving efficiency and replacing manpower in factories, logistics, construction and other scenarios.

Efficient and stable

Adopting high-performance motors and precision transmission systems, it can achieve fast and smooth lifting operations, greatly improve material handling efficiency, and ensure stable and reliable operation.

Super durable

Equipped with high-strength alloy chains and anti-corrosion design, it is wear-resistant and heavy-load-resistant, suitable for high-frequency industrial use, significantly extending the life of the equipment and reducing maintenance costs.

Safe and reliable

Integrated with multiple safety devices such as overload protection, emergency brakes and limit switches to effectively prevent accidents and ensure the absolute safety of operators and goods.

Flexible and versatile

The compact and lightweight design is suitable for narrow spaces. It can be used independently or integrated into the crane system to meet the lifting needs of multiple scenarios such as production lines, warehouses, and buildings, and has a wide range of applications.

Didn't find your industry solution? Consult our technical experts immediately.

Get Customized Quote

Parameter

Parameters	Specifications	Remark
Rated load	0.25T~10T	Supports non-standard customization (up to 20T)
Standard lifting height	3m / 6m / 9m / 12m / 15m / 18m	Can customize higher travel (up to 30m)
Lifting speed	- Single speed: 4~8 m/min	Optional frequency conversion speed regulation (0.5~10 m/min stepless speed regulation)
Lifting speed	- Dual speed: normal speed 4~8 m/min, slow speed 1~2 m/min
Motor characteristics	- Power: 0.4kW~7.5kW	Can be equipped with explosion-proof motor (Ex dⅡBT4)
	- Insulation class: Class F
	- Protection class: IP54/IP65
Power supply specifications	220V/380V/415V/440V, 50Hz/60Hz	Support global voltage adaptation
Chain configuration	- Material: alloy steel (surface carburizing and hardening)	Optional stainless steel chain (anti-corrosion environment)
	- Standard: ISO/DIN standard
	- Safety factor: ≥4:1
Duty system	S3 (intermittent duty), load rate 40%~60%	Can be upgraded to S4/S5 working system
Control mode	- Handle button control	Support PLC integrated control
	- Wireless remote control (10~30m)
	- Frequency conversion control cabinet (precise positioning)
Safety protection	Overload protection + mechanical limit + emergency brake + phase loss protection + thermal protection	Optional overload alarm system
Environmental adaptability	- Temperature: -20℃~+60℃	High temperature/low temperature special models are available
Environmental adaptability	- Humidity: ≤90% RH (no condensation)

Note:
The above parameters are standard model configurations. Customized solutions (such as explosion-proof type, anti-corrosion type, etc.) can be provided according to customer needs.

Application

With its compactness, lightness, safety and durability, Electric Chain Hoist is widely used in high-frequency lifting of manufacturing production lines, cargo handling in logistics warehousing, material lifting at construction sites, equipment lifting in auto repair shops, as well as industrial fields such as shipbuilding and power maintenance. Its flexible installation method is particularly suitable for working environments with limited space, and it can also meet the diverse needs of precision instrument handling and heavy equipment installation. It is an indispensable and efficient lifting solution in modern industrial production and engineering construction.
