| Parameters |
Specifications |
Remark |
| Rated load |
5 Ton Hoist(5000kg) |
The chain hoist lifting capacity is strictly prohibited to exceed 3 tons |
| Standard lifting height |
3m / 6m / 9m / 12m / 15m / 18m |
Can customize higher travel (up to 30m) |
| Lifting speed |
- Single speed: 4~8 m/min |
Optional frequency conversion speed regulation (0.5~10 m/min stepless speed regulation) |
| - Dual speed: normal speed 4~8 m/min, slow speed 1~2 m/min |
| Motor characteristics |
- Power: 0.4kW~7.5kW |
Can be equipped with explosion-proof motor (Ex dⅡBT4) |
| - Insulation class: Class F |
| - Protection class: IP54/IP65 |
| Power supply specifications |
220V/380V/415V/440V, 50Hz/60Hz |
Support global voltage adaptation |
| Chain configuration |
- Material: alloy steel (surface carburizing and hardening) |
Optional stainless steel chain (anti-corrosion environment) |
| - Standard: ISO/DIN standard |
| - Safety factor: ≥4:1 |
| Duty system |
S3 (intermittent duty), load rate 40%~60% |
Can be upgraded to S4/S5 working system |
| Control mode |
- Handle button control |
Support PLC integrated control |
| - Wireless remote control (10~30m) |
| - Frequency conversion control cabinet (precise positioning) |
| Safety protection |
Overload protection + mechanical limit + emergency brake + phase loss protection + thermal protection |
Optional overload alarm system |
| Environmental adaptability |
- Temperature: -20℃~+60℃ |
High temperature/low temperature special models are available |
| - Humidity: ≤90% RH (no condensation) |
Note:
The above parameters are standard model configurations. Customized solutions (such as explosion-proof type, anti-corrosion type, etc.) can be provided according to customer needs.
How to Choose the Right 5-Ton Chain Hoist
1. Lifting Height: The lifting height of the chain hoist must be greater than your actual required height, as you need to allow for chain storage and safety margin.
2. Working Level: This is a key indicator of the hoist's working intensity. Do you need to use it occasionally, or frequently every day?
3. Power Supply: What power supply does your work site provide?
Standard Three-Phase (380V/50Hz): Most common, supported by all models.
Single-Phase (220V): If only household power or a specific workshop is available.
4. Installation Method:
Fixed: Directly fixed via overhead lifting points, position remains unchanged. This is the simplest method.
Rotating: This is the most common method. The hoist needs to move left and right on an I-beam.
5. Control Method:
Handle Control: Most commonly used, integrates all buttons and emergency stop switch.
Remote Control: Long-distance operation, safer and more convenient, especially suitable for large workshops or hazardous areas.
