F Series 3-in-1 Gearbox

Model No.: FA37-FA157

Gear Ratio: 4-200

Nominal Torque Tn(N.m) : 110-18000

Motor Power: 0.3-248

Chat Now

Leave Message

Send Email:info@craneweihua.com

Whatsapp:8613839050298

Overview

Features

Application

Overview

The three-in-one reducer is an integrated transmission device that integrates a reducer, motor, and brake. It has the characteristic of parallel output with the motor shaft and is mainly used in industrial scenarios such as gantry cranes, roller conveyor lines, and lifting mechanisms. Its core function is to reduce speed and increase torque. It transmits the motor power to the output shaft through gear transmission and uses the tail electromagnetic brake to achieve precise braking.

This gearbox utilizes high-quality alloy steel gears and shafts, carburized, quenched, and ground for enhanced hardness and precision. The housing features an integrated design with dual bearings and a cushion sleeve for enhanced input shaft stability. It supports a variety of output configurations, including hollow spline and parallel key shafts, and offers mounting options including torque support holes, base mounts, and flange mounts. Standard reduction ratios range from 4 to 200, with customization available to meet the compact transmission requirements of various industrial equipment.

Features

The "three-in-one" reducer integrates a reducer, an electric motor and a brake into one, and has the characteristics of parallel output with the motor shaft, compact structure, large torque transmission, stable operation, low noise and long life.

Highly integrated, lightweight design

Three-in-one structure: Integrates the motor, electronic control, and reducer into one unit, reducing redundant components and weight (20%-30% lighter than traditional split-type units).

Long service life

This "three-in-one" reducer integrates a reducer, motor, and brake. It features a vertical output to the motor shaft, a compact structure, high torque transmission, smooth operation, low noise, and a long service life.

High performance and reliability

High power density motor: Permanent magnet synchronous motor (PMSM) with oil cooling technology, delivering continuous high torque output

Smooth operation and low noise

The reducer gears and gear shafts are made of high-quality alloy steel. After carburizing, quenching, and grinding, the tooth surfaces are highly hard and precise, resulting in low transmission noise.

Didn't find your industry solution? Consult our technical experts immediately.

Get Customized Quote

Application

Three-in-one integrated reducers combine the motor, electronic control unit (MCU, motor controller), and reducer (gearbox) into a single modular unit, reducing size, weight, and energy loss while improving efficiency. Primarily used in crane operating mechanisms such as gantry cranes and electric hoists, this series of reducers can also be used in transmission mechanisms in various mechanical equipment, including transportation, metallurgy, mining, petroleum, chemical, construction, railways, ports, defense engineering, and the textile industry.
